Home / Collections / All / 4.8KWH | 600W - Victron Energy

4.8KWH | 600W - Victron Energy


  • Details
  • Description
  • Lithium Technology

    Flat discharge curve holds above 12V for up to 90% of its capacity usage providing huge boosts in run-time compared to only 50% in Lead Acid.

  • >2500 Charge Cycles

     2500 - 7000 cycles and a 10 year lifetime cycle use.

  • Environmentally Friendly

    ISO 9001, UL, & ROHS Certifications for every battery.



  • DOT, IATA, and CAB Certified

    Approved for transport by Ground, Air, and Sea

  • Lithium Technology

    Flat discharge curve holds above 12V for up to 90% of its capacity usage providing huge boosts in run-time compared to only 50% in Lead Acid.

  • >2500 Charge Cycles

     2500 - 7000 cycles and a 10 year lifetime cycle use.

  • Environmentally Friendly

    ISO 9001, UL, & ROHS Certifications for every battery.

  • DOT, IATA, and CAB Certified

    Approved for transport by Ground, Air, and Sea

  • SLA Technology

    Absorbent Glass Mat Technology

  • ABS Impact Resistant Case

    Rugged Impact Resistant Case and Cover

  • UL Certification

    ISO 9001, ISO 14001, ISO 45001, and UL certifications for every battery.

  • DOT, IATA, and CAB Certified

    Approved for transport by Ground, Air, and Sea.

The Solar System Kit includes six 100W Solar Panels, a Victron 50A MPPT Solar Charge Controller, two of the 12V 200Ah VRLA SLA (AGM/GEL) Deep Cycle battery, a Victron 30A DC-to-DC Charger, a Victron 12V 3000W Pure Sine Wave Inverter Charger, a pair of 3-in-1 connection cables to create a 2S3P configuration for the six panels, a pair of 20ft 10AWG Solar Cables, a pair of 6ft 8AWG Battery Cables, and six sets of solar panel Mounting Brackets.

This kit is ideal for RV, Van, or Boat solar projects, offering multiple charging methods for the deep cycle battery including solar, starter battery/alternator, and other charging sources such as shore power or a generator. The kit simplifies the process of purchasing and setting up a complete off-grid solar system. With the 200Ah battery providing 4,800Wh of backup power and the six 100W solar panels capable of generating up to 3,000Wh for the batteries (calculated based on 5 peak hours), uninterrupted operation is achievable indefinitely.

This kit contains:

6 x 100W Monocrystalline Solar Panel

6 x Panel Mounting Brackets

2 x VRLA SLA (AGM/GEL) Deep Cycle Battery

1 x 3-in-1 Connection Adapter for 2S3P panel connection

1 x Victron SmartSolar MPPT 100/50 (SCC110050210)

1 x Victron Orion-Tr Smart DC-DC Charger 12 | 12-30 (ORI121236120)

1 x Victron MultiPlus 12V 3000W 120V Inverter Charger (PMP122301102)

1 x 20ft 10AWG Panel Cable to Controller

1 x 6ft 8AWG Controller Cable to Battery

Save 0 %
4.8KWH | 600W - Victron Energy

$3,199.99

  • Details
  • Description
  • Lithium Technology

    Flat discharge curve holds above for up to 95% of its capacity usage providing huge boosts in run-time compared to only 50% in Lead Acid.

  • >2500 Charge Cycles

     2500 - 7000 cycles and a 10 year lifetime cycle use.

  • Environmentally Friendly

    ISO 9001, UL, and ROHS Certifications for every battery.

  • Built-in Safety System

    Unique built-in Battery Management System (BMS) protects our LiFePO4 batteries from overcharge, deep discharge, overloading, overheating, short circuit, and excessive low self-discharge rate. This built-in system can ensure up to 1-year of maintenance-free storage.

  • Lithium Technology

    Flat discharge curve holds above 12V for up to 90% of its capacity usage providing huge boosts in run-time compared to only 50% in Lead Acid.

  • >2500 Charge Cycles

     2500 - 7000 cycles and a 10 year lifetime cycle use.

  • Environmentally Friendly

    ISO 9001, UL, & ROHS Certifications for every battery.



  • DOT, IATA, and CAB Certified

    Approved for transport by Ground, Air, and Sea

  • SLA Technology

    Absorbent Glass Mat Technology

    .

  • ABS Impact Resistant Case

    Rugged Impact Resistant Case and Cover

  • UL Certification

    ISO 9001, ISO 14001, ISO 45001, and UL certifications for every battery.

  • DOT, IATA, and CAB Certified

    Approved for transport by Ground, Air, and Sea

The Solar System Kit includes six 100W Solar Panels, a Victron 50A MPPT Solar Charge Controller, two of the 12V 200Ah VRLA SLA (AGM/GEL) Deep Cycle battery, a Victron 30A DC-to-DC Charger, a Victron 12V 3000W Pure Sine Wave Inverter Charger, a pair of 3-in-1 connection cables to create a 2S3P configuration for the six panels, a pair of 20ft 10AWG Solar Cables, a pair of 6ft 8AWG Battery Cables, and six sets of solar panel Mounting Brackets.

This kit is ideal for RV, Van, or Boat solar projects, offering multiple charging methods for the deep cycle battery including solar, starter battery/alternator, and other charging sources such as shore power or a generator. The kit simplifies the process of purchasing and setting up a complete off-grid solar system. With the 200Ah battery providing 4,800Wh of backup power and the six 100W solar panels capable of generating up to 3,000Wh for the batteries (calculated based on 5 peak hours), uninterrupted operation is achievable indefinitely.

This kit contains:

6 x 100W Monocrystalline Solar Panel

6 x Panel Mounting Brackets

2 x VRLA SLA (AGM/GEL) Deep Cycle Battery

1 x 3-in-1 Connection Adapter for 2S3P panel connection

1 x Victron SmartSolar MPPT 100/50 (SCC110050210)

1 x Victron Orion-Tr Smart DC-DC Charger 12 | 12-30 (ORI121236120)

1 x Victron MultiPlus 12V 3000W 120V Inverter Charger (PMP122301102)

1 x 20ft 10AWG Panel Cable to Controller

1 x 6ft 8AWG Controller Cable to Battery

SPECIFICATIONS

REVIEWS

DOWNLOADS

FEATURES

SPECIFICATIONS

DOWNLOADS


Kit Includes


OR

specifications

  • 200Ah SLA Battery
    Battery
  • 100W Solar Panel
    Solar Panel
  • 50A MPPT Victron Controller
    Controller
  • DC-DC Victron Charger
    Bluetooth
  • 3KW Victron Inverter Charger
    Bluetooth

Option 1: AGM Battery



DIMENSIONS

Length

Width

20.59 in

9.45 in

Height

Height w/ Terminals

8.62 in

8.82 in


DETAILS

Voltage

Capacity

12V

200Ah

Color

Battery Life

Black

Stand By: 3~5 Years

Terminal Type

Weight

M8

132.28 Lbs

Chemistry

Cycle Use

VRLA AGM

50% Depth Discharge 500 Times

Cells

Polarity



[+ -]

UPC

SKU




WARRANTY / CERTIFICATIONS

Certification

UL, CE, ISO

Warranty

1 Year

Option 2: Gel Battery



DIMENSIONS

Length

Width

20.55 in

9.4 in

Height

Height w/ Terminals

8.54 in

8.74 in


DETAILS

Voltage

Capacity

12V

200Ah

Color

Battery Life

Black & Gold

Stand By: 3~6 Years

Terminal Type

Weight

M8 Threaded Insert

127.87 lbs

Chemistry

Cycle Use

VRLA Gel

1900~2100 cycles @30% DoD

Cells

Polarity



[+ -]

UPC

SKU




WARRANTY / CERTIFICATIONS

Certification



Warranty

1 Year


PHYSICAL DETAILS

Dimensions

Weight

35.43 x 22.83 x 1.18 in

12.6 Lbs

Cells

Connections

Monocrystalline solar cells

PV


INTERNAL SPECS

Rated Voltage [Vmpp]
Rated Current [Impp]
Open Circuit Voltage [Voc]

Short Circuit Current [Isc]

Max Series Fuse Rating

18.81V

5.32A

22.2V

5.6A

15A

Power Temp Coefficient

Voltage Temp Coefficient

Current Temp Coefficient

Max. System Voltage

–0.45% / °C

-0.37% / °C

0.1% / °C

1000VDC


WARRANTY / CERTIFICATIONS

Certification

UL

Warranty

1 Year


PHYSICAL DETAILS

Dimensions

Weight

7.2 x 4.5 x 2.25 in

2.25 Lbs

Terminals

Battery Compatibility
Battery Compatibility

Up to #7AWG

SLA, Flooded, Gel, AGM, LiFePo4


INTERNAL SPECS

Nominal Voltage

Rated Charge Current

Max. PV Input Voltage

Self-Consumption

12/24V Auto Recognition

40A

100V

≤10mA

Enclosure

Temp. Compensation


Temperature Ranges


IP32

-3mV/℃/2V

Operational:  -31°F — 113°F


Storage:        -31°F — 176˚F


WARRANTY / CERTIFICATIONS

Certification

CE / EMC Certifications

Warranty

1 Year

Input voltage range: 10-17V --- Output voltage adjust range: 10-15V --- Cont. output current at nominal output voltage and 40°C: 30A --- Maximum output current (10 s) at nominal output voltage minus 20%: 40A




PHYSICAL DETAILS

Dimensions

Weight

4.68 x 2.95 x 1.08 in

0.27 Lbs

Noise

Battery Compatibility
Battery Compatibility



SLA, Flooded, Gel, AGM, LiFePo4


INTERNAL SPECS

Rated Input Voltage

Rated Output Voltage

Output Voltage Range

Nominal Output Frequency

Efficiency











Automatic Shut-Down:

Low DC Input Voltage

High DC Input Voltage





Recovery:

High DC input voltage



Low Battery Alarm

Battery Charger Current

Power-saving mode

Power saving on

Humidity



Overload Protection






Overload Protection








Overload Protection





Temperature Ranges

















WARRANTY / CERTIFICATIONS

Certification

CE / EMC Certifications

Warranty
